Lithium Battery Equipment Manufacturer: Winding Machine Visual Inspection System
Pain Points and Requirements
The winding process is a crucial step in the production of cylindrical batteries and some square cell battery cores. The core of the process lies in the dimensions and precision of winding the electrodes and separators. Improper handling can lead to internal short circuits in the final battery products. The customer needs to integrate a more agile visual system into the equipment to perform positioning correction and inspection, further enhancing the overall performance of the equipment.
Solution
- Hardware: High-frame-rate dual telecentric lenses + parallel acquisition with multiple line scan cameras
Enhanced Quality and Efficiency
- Zero missed detections
- Detection speed ≥ 200m/min
- Detection accuracy ±0.05mm
FALenses Technology specializes in providing machine vision core hardware. You can go to the official website of FALenses Technology at https://www.falenses.com/ for more information.
