- APOCHROMATIC LENS 95mm APO long WD metallurgical objective lens
Specifications |
|||||||||||||
| 95mm APO long WD metallurgical objective lens | |||||||||||||
| MODEL | PN | TYPE | N.A | W.D (mm) | FL (mm) | TL (mm) | 25OFN (mm) | 1”相机 | RES (μm) | DOF±Δ (μm) | SCREW | Length (mm) | Dia. (mm) |
| M Plan APO 2X | 2X | BF | 0.055 | 34 | 100 | F=200 | 12 | 4.8x6.4 | 5 | 91 | M26 | 66.5 | 34 |
| M Plan APO 5X | 5X | BF | 0.15 | 44.9 | 40 | F=200 | 4.8 | 1.92X2.56 | 2.5 | 14 | M26 | 55.65 | 34 |
| M Plan APO 10X | 10X | BF | 0.3 | 33.9 | 20 | F=200 | 2.4 | 0.96X1.28 | 1 | 3.5 | M26 | 66.6 | 34 |
| M Plan APO 20X | 20X | BF | 0.45 | 20.1 | 10 | F=200 | 1.2 | 0.48X0.64 | 0.7 | 1.55 | M26 | 80.45 | 34 |
| M Plan APO 50X | 50X | BF | 0.65 | 9.4 | 4 | F=200 | 0.5 | 0.19X0.26 | 0.4 | 0.61 | M26 | 91.1 | 34 |
| M Plan APO 20X ELWD | ELWD | BF | 0.3 | 30.9 | 10 | F=200 | 1.2 | 0.48X0.64 | 1 | 3.2 | M26 | 69.65 | 34 |
| M Plan APO 50X ELWD | ELWD | BF | 0.45 | 20.1 | 4 | F=200 | 0.5 | 0.19X0.26 | 0.7 | 0.9 | M26 | 80.45 | 34 |
| M Plan APO 100X | 100X | BF | 0.8 | 6 | 2 | F=200 | 0.24 | 0.1X0.13 | 0.4 | 0.4 | M26 | 94.5 | 36 |
